Kia Optima: [REMY]
|
1. Front bracket 2. Stop ring 3. Stopper 4. Overrun clutch assembly 5. Internal gear assembly 6. Lever |
7. Lever packing 8. Magnet switch assembly 9. Planet shaft assembly 10. Planetary gear assembly 11. Packing 12. Shield |
13. Armature assembly 14. Yoke assembly 15. Brush holder assembly 16. Rear bracket 17. Through bolt |
[VALEO]
1. Front bracket
2. Stop ring
3. Stopper
4. Overrun clutch assembly
5. Internal gear assembly
6. Lever
7. Lever stop
8. Magnet switch assembly
9. Driv ...
