Kia Optima: [VALEO]
|
1. Front bracket 2. Stop ring 3. Stopper 4. Overrun clutch assembly 5. Internal gear assembly |
6. Lever 7. Lever stop 8. Magnet switch assembly 9. Drive shaft assembly 10. Gasket sheet |
11. Armature assembly 12. Yoke assembly 13. Adjuster washer 14. Complete rear part assembly 15. Through bolt |
[REMY]
1. Front bracket
2. Stop ring
3. Stopper
4. Overrun clutch assembly
5. Internal gear assembly
6. Lever
7. Lever packing
8. Magnet switch assembly
9. P ...
