Service Standard
Item
Specification
Ignition Timing (°)
BTDC 6 ± 10
Idle Speed (rpm)
A/C OFF
Neutral, N, P-range
70 ...
High Mounted stop lamp Repair procedures
Removal
1.
Disconnect the negative(-) battery terminal.
2.
Remove the rear seat.
(Refer to the BD group - "Rear seat")
3.
Remove the package tray trim (A).
(Refer to the BD group -"Inter ...
Installation
1.
Installation is the reverse of
removal.
2.
Perform the “Assembly check”
with GDS.
3.
Check that the brake operates
normally by pushing the EPB ...
