Kia Optima: Muffler. Components and Components Location - Intake And Exhaust System - Engine Mechanical System - Kia Optima TF 2011-2020 Service ManualKia Optima: Muffler. Components and Components Location

Components




1. Front muffler
2. Catalytic converter & center muffler assembly
3. Main muffler
4. Gasket
5. Hanger
