Kia Optima: Intercooler. Components and Components Location - Intake And Exhaust System - Engine Mechanical System - Kia Optima TF 2011-2021 Service ManualKia Optima: Intercooler. Components and Components Location

Components




1. Recirculation hose
2. Intercooler inlet hose A
3. Intercooler inlet pipe
4. Intercooler inlet hose B
5. Recirculation Solenoid Valve
6. Boost pressure sensor
7. Intercooler outlet hose A
8. Intercooler outlet pipe
9. Intercooler outlet hose B
10. Intercooler mounting bracket
11. Radiator lower mounting insulator
12. Intercooler
13. Intercooler lower mounting insulator
14. Air guide
