Kia Optima: Steering Gear box. Components and Components Location - Electric Power Steering - Steering System - Kia Optima TF 2011-2026 Service ManualKia Optima: Steering Gear box. Components and Components Location

Components

1. Tie rod end
2. Lock nut
3. Bellows
4. Bellows band
5. Tie rod
6. Rack bar
7. Dust packing
8. Dust cap
9. Oil seal
10. Pinion plug
11. Pinion assembly
12. Yoke plug
13. Yoke spring
14. Support yoke assembly
15. Rack housing


Inspection
1. Check the steering column for damage and deformation. 2. Check the joint bearing for damage and wear. 3. Check the tilt bracket for damage and ...
