Kia Optima: Components and Components Location - Cylinder Block - Engine Mechanical System - Kia Optima TF 2011-2025 Service ManualKia Optima: Components and Components Location




1. Piston ring
2. Snap ring
3. Piston
4. Connecting rod
5. Connecting rod upper bearing
6. Piston pin
7. Connecting rod lower bearing
8. Connecting rod bearing cap
9. Ladder frame
10. Oil filter bracket
11. Crankshaft rear oil seal




1. Crankshaft upper bearing
2. Thrust bearing
3. Crankshaft
4. Crankshaft lower bearing
5. Main bearing cap
6. Piston cooling oil jet


Cylinder Block
...

Repair procedures
...
