Kia Optima: Schematic Diagrams
System Block Diagram
|
Component part |
Function |
|
|
Vehicle speed sensor |
Converts vehicle speed to pulse. |
|
|
ECM |
Receives signals from sensor and control switches. |
|
|
Cruise control indicator |
Illuminate when CRUISE main switch is ON (Built into
cluster) |
|
|
Cruise control switches |
ON/OFF switch |
Switch for automatic speed control power supply. |
|
Resume/Accel switch |
Controls automatic speed control functions by Resume/Accel
switch (Set/Coast switch) |
|
|
Set/Coast switch |
||
|
Cancel switches |
Cancel switch |
Sends cancel signals to ECM. |
|
Brake pedal switch |
||
|
Transaxle range switch (A/T) |
||
|
ETS motor |
Regulates the throttle valve to the set opening by ECM. |
|
* ETS : Electronic Throttle System
Description and Operation
Cruise Control
The cruise control system is engaged by the cruise "ON/OFF"
main switch located on right of steering wheel column. The system has the capability
to cruise, coast, accel ...
