Components
EPB Switch. Repair procedures
Remove
1.
Turn ignition OFF and disconnect
the negative (-) battery cable.
2.
Remove the floor console upper
cover.(Refer to Body group - "Console")
...
PWM Blower Module Repair procedures
Inspection
1.
Ignition "ON"
2.
Manually operate the control switch and measure the voltage of blower motor.
3.
Select the control switch to raise voltage until high speed.
BLOWER speed ...
Tripmeter (If equipped)
TRIP A : Tripmeter A
TRIP B : Tripmeter B
The tripmeter indicates the distance of individual trips selected by the driver.
Tripmeter A and B can be reset to zero by pressing the mode selection but ...
