Kia Optima: Radiator. Components and Components Location - Cooling System - Engine Mechanical System - Kia Optima TF 2011-2021 Service ManualKia Optima: Radiator. Components and Components Location

Components




1. Cooling fan assembly
2. Radiator
3. Mounting insulator
4. Radiator mounting bracket
5. Radiator upper hose
6. Radiator lower hose
7. Reservoir tank
8. Over flow hose
9. ATF cooler hose
