Kia Optima: Intake Manifold. Components and Components Location - Intake And Exhaust System - Engine Mechanical System - Kia Optima TF 2011-2019 Service ManualKia Optima: Intake Manifold. Components and Components Location

Components




1. Intake manifold assembly
2. Electronic throttle body
3. Intake manifold stay
4. Intake manifold gasket


Intake And Exhaust System
...

Intake Manifold. Repair procedures
Removal and Installation 1. Remove the engine cover. 2. Disconnect the battery negative terminal (A). Tightening torque4.0 ~ 6.0N.m (0.4 ~ 0.6kgf.m, 3. ...
