Kia Optima: Alternator. Components and Components Location - Charging System - Engine Electrical System - Kia Optima TF 2011-2019 Service ManualKia Optima: Alternator. Components and Components Location

Components

1. Pulley
2. Front bracket
3. Front bearing
4. Bearing cover
5. Bearing cover bolt
6. Rotor
7. Rear bearing
8. Rear bracket
9. Through bolt
10. Regulator assembly
11. Regulator bolt
12. Rear cover


Repair procedures
On-vehicle Inspection • Check that the battery cables are connected to the correct terminals. ...

Alternator. Repair procedures
...

See also:

Removal
1. Remove the head lamp leveling unit connector (A). 2. Loosen the mounting bolts (3EA) of automatic head lamp leveling unit assembly. Tighting torq ...

Installation
1. Installation is the reverse of removal. Use a new washer (A) whenever installing. ...
